1. heat exchanger
adopt excellent thermal performance copper tube and special pvc material filled as auxiliary cooling; optimize the arrangement and moderate tilt angle so that the cooling performance is more remarkable. copper tube connected with screw.
2. packing
unique design of the pvc packing, high cooling efficiency, corrosion resistance, excellent high temperature resistant performance, packing special design for easy cleaning and installation, water flowing rate (splash rate) 0.001%.
3.fan
for stringent noise requirements, compared with ordinary aluminum plate, use airfoil a-alloy fan, the noise is greatly reduced.
4.lower sink
adopt the frp material, more than two modules use the leak-proof sealed pad to connect, avoided the scene to connect the sink and shorten the installation time. acclivitous design makes the clean-up easier.
5.inner structure
capacious overhaul aisles and the optimization design of the internal tubing not only improve the tube life used, but also enhance the uniformity of the spraying water.
6.motors and water pump
our configuration for totally enclosed waterproof ultra low noise cooling tower are second to none for quality, reliability and performance. we help you
optimize energy management and cost savings to make more competitive. electric motor ip code ≥ip55; insulation levels f.
7.cooling tower shell
using pvc or frp plate.
8.cooling tower shell frame
using steel, increase the connection strength and the tower body strength . because of increased the thickness of steel plate, made of zinc leaching strength is higher.
9.advanced drive system design
①
hollow aluminum alloy with high strength, light weight, easy to adjust balance, big air volume, etc.
②totally enclosed motor fan motor adopts heavy load type, long service life.
③tct large unit adopts multiple trough belt drive system, has the very high lateral stiffness, belt made out of neoprene and polyester line, durable. belt, drive system, pulley driven protection cover protection, which can make the whole system under the condition of more secure operation, make the drive systems is not influenced by environmental conditions, guarantee the service life of the unit, reduces the risk of downtime due to failure.
optional accessories
1.shock absorber
whirling blower on the top of tower body will come into being microseism which may spread to buildings. we supply specialized multiple solutions to diminish oscillation maximally.
ⅰspecial spring shock-absorbing seats
ⅱspecial rubber shock-absorbing pads
2.electric heater
circulating water and spray water can freeze during cold winter months,which can bring out the disruption of pipes.we recommend electric heater and automatic control equipment to prevent fracture accident.if you need other antifreeze way you can contact the company.
3.outtake cylinder
we supply straight tube 45° syphon or 90° syphon based on consumer requirement.
4.motor
we offer single-speed, double speed motor, and variable frequency motor for the customer choice,to meet customer’s need.
5.electronic control box
it can control the pumps, motors, electric heaters and other equipment necessary to control the centralized management, it’s facilitate and security and remote control can be achieved.
6.water tank
also we can provide the replenishment of water tanks.
7.medicine tank
we supply medicine tank for different requirement of water quality.
